AFTERMARKET FILTER REPLACEMENTS MADE IN THE USA.
| |
Part Type: |
Hydraulic |
| |
Element Type: |
Return Line |
| |
Product Media: |
Glass/Water Removal |
| |
Height: |
6.710 |
| |
OD Top: |
2.028 |
| |
OD Bottom: |
2.028 |
| |
ID Bottom: |
0.874 |
| |
BPVS_Setting (PSI): |
44 |
| |
Collapse Pressure (PSI): |
435 |
| |
Operating Temp Min (F): |
-13 |
| |
Operating Temp Max (F): |
248 |
| |
Capacity (GR): |
8 |
| |
Filter Area (SQ IN): |
87 |
| |
Flow Direction: |
Outside-In |
| |
Gasket Material: |
Viton |
| |
Fluid Type: |
HH / HL / HM / HV |
| |
Beta Ratio 1: |
200/20.7 |
| |
Beta Ratio 2: |
1000/26.6 |
| |
Micron 1: |
20 |
| |
Weight (LBS): |
0.572 |
|
